Technical specification :
Brand : ProVia
Part type : Reliable spare parts
Max. operating pressure : 10.0 bar
Max. temporarily pressure : 13 bar
Mounting : 4x M8
Opening pressure : 0.5 bar
Operating pressure : 10.0 bar
Port thread 1 : M22 x 1.5
Port thread 2 : M22 x 1.5
Port thread 4 : M16 x 1.5
Ports : 1, 2: M22 x 1.5; 4: M16 × 1.5
Predominance : 0.20 bar
ProVia warranty : 1 year
Product category : Device
Regulating ratio : 1:1
Response pressure : 0.20 bar
Technical specification : AM specification
Temperature range : -40°C to +80°C
Type of lever fixing : Ball Ø 10
Version : Pressure reduction
Calculated Volume (dm³) : 2.3438
Size (mm x mm x mm) : 125 x 125 x 150
UPC : 193134001712
Weight (kg) : 0.662
Weight (lb) : 1.4595
Replaces :
ALEXANDER DENNIS : AB9730110000
ASHOK LEYLAND : 445332009
DAEWOO : 3454401550
DAF : 1505410
DAF : 5021172710
DAF : 0689331
DAF : 1082666
DAF : 1444054R
DAF : 1506486R
DAF : 1519331
DAF : 3162118
DAF : 317315
DAF : 42125234
DAF : 689331
DAF : MZK4110
DOLL : 7019169
ERF : 4047273
EVOBUS : 8285438000
EVOBUS : 82855140000
EVOBUS : A0034291344
FAUN : 99707731617
FAYMONVILLE : 0319
FELDBINDER : 001546
FORD : 4C462K422AA
FRUEHAUF : A21316000003047B
