Technical Specifications

• Brand : WABCO Original
• Part type : Premium original quality
• Technical Specification : OE specification
• Product Category : Device
• Closing pressure static 21 : 4.5 bar
• Closing pressure static 22 : 4.5 bar
• Closing pressure static 23 : 4.5 bar
• Closing pressure static 24 : 4.5 bar
• Electrical Connection : DIN 72585 A1-2.1-1-Sn/K2
• Max. operating pressure : 12.5 bar
• Opening pressure 21 : 7.5 bar
• Opening pressure 22 : 7.5 bar
• Opening pressure 23 : 7.2 bar
• Opening pressure 24 : 7.5 bar
• Opening pressure 25 : 8.5 bar
• Port thread 12 : M12 x 1.5
• Port thread 24 : M12 x 1.5
• Port thread 4 : M12 x 1.5
• Temperature range : -40°C to +65°C
• Voltage : 24 V
• Calculated Volume (dm³) : 33.744
• Size (mm x mm x mm) : 370 x 240 x 380
• UPC :193133361008
• Weight (kg) : 8.228
• Weight (lb) : 18.14
