Criteria
| Height [mm]: | 141,75 mm |
| Cylinder Bore [mm]: | 128,00 mm |
| Machined: | with cut-out for oil jet |
| Bolt Ø [mm]: | 46 mm |
| Supplementary Article/Info 2: | with piston ring carrier |
| Component Number: | 08-283100-00 |
| Compression Height [mm]: | 89,750 mm |
| Recess Diameter [mm]: | 81,200 mm |
| Bolt length [mm]: | 105 mm |
| Recess Depth 1 [mm]: | 21,600 mm |
| Valve pocket depth 1 [mm]: | 2,100 mm |
| Standard Size [STD]: | yes |
| Piston Clearance [mm]: | 0,140 mm |
